## Patio Layout #1 (4 PATTERN SETS SHOWN)

### How to calculate what you need:

*If your area is 100 square foot (for example) you will need 100 sf divided by 15.5 sf = 6.45 pattern sets. This is how many sets are required. Round up to 7 complete pattern sets.

*Multiply the number of pattern sets required by each size: (example)

- 7 sets x 3 = 21 pcs 12" X 12"
- 7 sets x 2 = 14 pcs 18" X 18"
- 7 sets x 2 = 14 pcs 12" X 24"
- 7 sets x 1 = 7 pcs 24" X 24"

## PATTERN #1

Nominal Size | QTY | SQ. FT |
---|---|---|

12" X 12" | 3 | 3 |

18" X 18" | 2 | 4.5 |

12" X 24" | 2 | 4 |

24" X 24" | 1 | 4 |

## TOTAL SQ. FT. PER PATTERN: 15.5

## Patio Layout #2 (4 PATTERN SETS SHOWN)

### How to calculate what you need:

*If your area is 100 square foot (for example) you will need 100sf divided by 7sf per the pattern = 14.29. This is how many sets are required. Round up to 15 complete pattern sets

*Multiply the number of pattern sets required by each size: (example)

- 15 sets x 1 = 15 pcs 12" X 12"
- 15 sets x 1 = 15 pcs 12" X 24"
- 15 sets x 1 = 15 pcs 24" X 24"

## PATTERN #2

Nominal Size | QTY | SQ. FT |
---|---|---|

12" X 12" | 1 | 1 |

12" X 24" | 1 | 2 |

24" X 24" | 1 | 4 |

## TOTAL SQ. FT. PER PATTERN: 7

## Patio Layout #3 (4 PATTERN SETS SHOWN)

Patterns such as this one with the pieces all being of the smaller size are recommended to be set in concrete.

### How to calculate what you need:

*If your area is 100 square foot (for example) you will need 100sf divided by 6sf per the pattern = 16.68. Round up to 17 complete pattern sets.

*Multiply the number of pattern sets required by each size: (example)

- 17 sets x 2 = 34 pcs 12" X 12"
- 17 sets x 2 = 34 pcs 12" X 24"

## PATTERN #3

Nominal Size | QTY | SQ. FT |
---|---|---|

12" X 12" | 2 | 2 |

12" X 24" | 2 | 4 |

## TOTAL SQ. FT. PER PATTERN: 6

## Patio Layout #4 (4 PATTERN SETS SHOWN)

### How to calculate what you need:

*If your area is 350 square foot (for example) you will need 350 sf divided by 45 sf per the pattern = 7.78 pattern sets. Round up to 8 complete pattern sets.

*Multiply the number of pattern sets required by each size: (example)

- 8 sets x 2 = 16 pcs 12" X 12"
- 8 sets x 4 = 32 pcs 12" X 18"
- 8 sets x 2 = 16 pcs 12" X 24"
- 8 sets x 1 = 8 pcs 12" X 30"
- 8 sets x 2 = 16 pcs 18" X 18"
- 8 sets x 2 = 16 pcs 18" X 24"
- 8 sets x 1 = 8 pcs 24" X 24"
- 8 sets x 2 = 16 pcs 24" X 30"
- 8 sets x 1 = 8 pcs 24" X 36"

## PATTERN #4

Nominal Size | QTY | SQ. FT |
---|---|---|

12" X 12" | 2 | 2 |

12" X 18" | 4 | 6 |

12" X 24" | 2 | 4 |

12" X 30" | 1 | 2.5 |

18" X 18" | 2 | 4.5 |

18" X 24" | 2 | 6 |

24" X 24" | 1 | 4 |

24" X 30" | 2 | 10 |

24" X 36" | 1 | 6 |

## TOTAL SQ. FT. PER PATTERN: 45

## PATTERN #5

Nominal Size | QTY | SQ. FT |
---|---|---|

12" X 12" | 7 | 7 |

12" X 18" | 9 | 13.5 |

12" X 24" | 6 | 12 |

12" X 30" | 4 | 10 |

18" X 18" | 4 | 9 |

18" X 24" | 11 | 33 |

18" X 30" | 2 | 7.5 |

24" X 24" | 2 | 8 |

## TOTAL SQ. FT. PER PATTERN: 100

## Patio Layout #5 (4 PATTERN SETS SHOWN)

### How to calculate what you need:

*If your area is 100 square foot (for example) you will need 100sf divided by 100sf per the pattern = 1. You need 1 complete pattern set.

*Multiply the number of pattern sets required by each size: (example)

- 1 sets x 7 = 7 pcs 12" X 12"
- 1 sets x 9 = 9 pcs 12" X 18"
- 1 sets x 6 = 6 pcs 12" X 24"
- 1 sets x 4 = 4 pcs 12" X 30"
- 1 sets x 4 = 4 pcs 18" X 18"
- 1 sets x 11 = 11 pcs 18" X 24"
- 1 sets x 2 = 2 pcs 18" X 30"
- 1 sets x 2 = 2 pcs 24" X 24"
